Global Mining10-FOOT JAW ROCK CRUSHER
Content


The GME10 Jaw Rock Crusher manufactured by Global Mining Equipment, LLC, is a rock crusher that is designed to take larger rock and crush them down to 1" (25mm) or smaller to further be reduced by the GME Hammer Mill for gold milling sites. This crusher is also used by Contractors and Landscapers to crush rock for demolition or to create a specific product for use.

This jaw crusher is able to crush rock/ore up to 8" (205 mm) in a very productive manner. The jaw rock crusher is built tough and priced well. The exciting feature is that you will be able to take this production Jaw Rock Crusher straight from the shipping container and be using it in less than 30 minutes.

NO WASTED TIME FINDING THE RIGHT ENGINE, SHEAVES, PULLEYS OR BELTS - JUST OPERATE THE MACHINE.

Jaw Rock Crusher

10-foot Wide Jaw Rock Crusher Features:

• The GME10 Jaw Rock Crusher is an assembled jaw crusher that is ready to use immediately upon receipt.

• The Jaw Rock Crusher is able to crush material up to 8" (20 5mm).

• The Jaw Rock Crusher is able to adjust the final output size from 1/4" (6 mm) to 3" (76 mm).

• The Jaw Rock Crusher can be fitted with an electric motor, gas engine, diesel engine or no engine.

• The flange and pillowblock bearings are the top of the line Blue Brute Bearings; these rugged bearings are used in the most harsh testing environments like rock crushing.

• The shaft is 2.4" (60mm) at the cam shaft and 2" (50 mm) at the drive shaft.

• The jaw rock crusher wear plates are 3/4" (19 mm) and are made of a hard faced 450 Brinnel Hardness Material.

• Also available is an upgraded cast manganese / chrome wear plates.

Specs:

• Drive System: 20HP Gas Engine / 18HP Diesel Engine / 10HP Electric Motor
• Height: 48" (1220 mm)
• Width: 32" (812 mm)
• Length: 56" (1422 mm)
• Weight: approx. 950 pounds (430 kg)
• Jaw Size: approx. 10" (254 mm) wide x 4 to 6" (102 - 152 mm) deep
